Delta VFD 7.5kW 400V VFD17AMS43ANSAA-MS300
Inverter/Variable Frequency Drive
Model : VFD17AMS43ANSAA
Capacity : 7.5KW, 10.0HP
Input: 3PH, 400-480V, 50-60Hz,
Output: 3PH, 0-480V, 0.1-599Hz,(ND)20.5A,(HD)17A
Brand: Delta,
Origin: Taiwan, Product of China
Warranty: One Year
Mobile Number: +880-1750668006
See More Products, Visit our Website: www.puresolutionbd.com
Model Name : VFD17AMS43ANSAA
Series : MS-300
Input Voltage – Phase : 460 V – 3 Phase
Motor Power Range : 10.0HP – 7.5KW
Frequency : 0-599Hz
Frame Size : A5
IP Level : IP 20
EMC Filter : Optional
Normal Duty* Amps : 20.5A
Heavy Duty** Amps : 17A
Weight: 2.8Kg
Dimensions : 4.29 (in) x 8.15 (in) x 6.06 (in)
* Normal duty: rated current 120% for 60 seconds; 150% for 3 seconds
** Heavy duty: rated current 150% for 60 seconds; 200% for 3 seconds
-
